QuMax for Robustel R5020 Lite

P/n: AR5020LM

INTEGRATED MULTI-BAND LTE & 5G PANEL ANTENNA + WI-FI OMNI ANTENNA + PLACE TO INSTALL Robustel R5020 Lite (ALL-IN-ONE)

QuMax for Robustel R5020 Lite is a high performance directional antenna designed for use in a variety of wireless communication applications. This all-in-one product consists of multi-band 5G and Wi-Fi antennas, integrated in IP67 enclosure. It offers 7.5 dBi gain and wide beam width, which makes it suitable for use in both urban and rural environments.

Apart from antenna elements, the set includes a PoE splitter, allowing to deliver both data and power using one Ethernet cable, while maintaining the Gigabit speeds of 5G technology.

Combining QuMax with R5020 Lite inside the antenna housing gives you complete outdoor solution with mulitple use scenatios such as transportation public, energy, mining IoT and more.

Why QuMax for Robustel R5020 Lite

Learn more about your profit

Embedded PoE splitter

Antenna perfectly matched with the router

Outdoor antenna works in any weather conditions, IP67

Made in Europe

QuMax for Robustel R5020 Lite

SPECIFICATION

PRODUCT DETAILS

5G / LTE ANTENNA SPECIFICATION

Wi-Fi antenna specification

MECHANICAL SPECIFICATION

FREQUENCY BANDS

COMPATIBLE ROUTERS

Frequency

0.617 - 0.96 GHz

1.7 - 2.7 GHz

3.3 - 4.6 GHz

4.7 - 6.0 GHz

Gain

0.617 - 0.96 GHz: 6 dBi

1.7 - 2.7 GHz: 7 dBi

3.3 - 4.6 GHz: 7 dBi

4.7 - 6.0 GHz: 5.5 dBi

Supported LTE bands

1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 46, 47, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, 106

Supported 5G bands

n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n46, n47, n48, n53, n65, n66, n67, n71, n77, n78, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n256

VSWR

<2.00, max <3.00

Beamwidth

80°/80° ±15°

Polarization

X (+-45degrees)

Impedance

50 Ω

PLOTS

PRODUCT DETAILS

VSWR for 5G/LTE antenna

VSWR for 5G/LTE antenna of QuMax for Robustel R5020 Lite

VSWR for Wi-Fi antenna

VSWR for Wi-Fi antenna of QuMax for Robustel R5020 Lite

Gain for 5G/LTE antenna

Gain for 5G/LTE antenna of QuMax for Robustel R5020 Lite

Gain for Wi-Fi antenna

Gain for Wi-Fi antenna of QuMax for Robustel R5020 Lite
PORT 1&3 - 5G/LTE from 650MHz to 950MHz
Elevation
Azimuth
PORT 1&3 - 5G/LTE from 1.71GHz to 2.17GHz
Elevation
Azimuth
PORT 1&3 - 5G/LTE from 2.3GHz to 2.7GHz
Elevation
Azimuth
PORT 1&3 - 5G/LTE from 3.3GHz to 3.8GHz
Elevation
Azimuth
PORT 1&3 - 5G/LTE from 4.2GHz to 4.6GHz
Elevation
Azimuth
PORT 1&3 - 5G/LTE from 5.0GHz to 5.9GHz
Elevation
Azimuth
PORT 2&4 - 5G/LTE from 650MHz to 950MHz
Elevation
Azimuth
PORT 2&4 - 5G/LTE from 1.71GHz to 2.17GHz
Elevation
Azimuth
PORT 2&4 - 5G/LTE from 2.3GHz to 2.7GHz
Elevation
Azimuth
PORT 2&4 - 5G/LTE from 3.3GHz to 3.8GHz
Elevation
Azimuth
PORT 2 - 5G/LTE from 4.2GHz to 4.6GHz
Elevation
Azimuth
PORT 2 - 5G/LTE from 5.0GHz to 5.9GHz
Elevation
Azimuth
Wi-Fi 2.4GHz and 5GHz and 6GHz
Elevation
Azimuth

ANY QUESTIONS?

contact us

DIMENSIONS

PRODUCT DETAILS
QuMax for Robustel R5020 LiteQuMax for Robustel R5020 Lite

WHAT'S IN THE BOX?

PRODUCT DETAILS

IN THE BOX

QuMax for Robustel R5020 Lite

Parts of QuMax for Robustel R5020 Lite
1 x
Parts of QuMax for Robustel R5020 Lite
1 x
Parts of QuMax for Robustel R5020 Lite
1 x QuRJ45
Parts of QuMax for Robustel R5020 Lite
2 x
Parts of QuMax for Robustel R5020 Lite
1 x 8mm wrench
Parts of QuMax for Robustel R5020 Lite
1 x
Parts of QuMax for Robustel R5020 Lite
4 x M6 x 18
Parts of QuMax for Robustel R5020 Lite
4 x
Parts of QuMax for Robustel R5020 Lite
4 x M8
Parts of QuMax for Robustel R5020 Lite
6 x M3
Parts of QuMax for Robustel R5020 Lite
5 x M4 x 40

Download

Datasheet QuMax for Robustel R5020 Lite
Download
3D MODEL
Download

USE CASES

BEST SPOTS FOR YOUR ANTENNA
Use case QuMax for Robustel R5020 Lite
Use case QuMax for Robustel R5020 Lite
Use case QuMax for Robustel R5020 Lite
