Antenna QuSector S38-12X-65

QuSector S38-12X-65 offers focused coverage for 5G small cell deployments in the 3.8–4.2 GHz band. With up to 12 dBi gain and a 65° horizontal beamwidth, it is suitable for indoor and outdoor installations using compatible 5G radio equipment.

This single-band, cross-polarized MIMO 4x4 panel antenna combines four antenna ports with ±45° polarization to support multi-stream operation. Its 65° horizontal and 30° vertical beamwidth helps direct coverage toward the intended area, making it well suited to small cells and private 5G networks at industrial sites, warehouses and enterprise campuses.

The directional radiation pattern supports targeted coverage where additional network capacity or local connectivity is needed. A high-quality injection-moulded IP67 enclosure protects the antenna in outdoor environments, while the adjustable pole mounting system allows precise alignment, helping installers adapt sector coverage to the layout of each deployment.
