Antenna QuSector S38-14X-65

QuSector S38-14X-65 provides broad sector coverage for 5G small cell deployments in the 3.8–4.2 GHz band. With up to 14 dBi gain, it combines wide horizontal coverage with a narrow vertical beam, helping focus signal energy on the intended service area.

This single-band, cross-polarized MIMO 4x4 panel antenna features four antenna ports and ±45° polarization to support multi-stream operation with compatible 5G radios. Its 65° horizontal and 15° vertical beamwidth makes it well suited to small cells and private 5G networks serving industrial facilities, logistics yards and enterprise campuses.

The concentrated vertical radiation pattern provides greater control over coverage when antenna height and tilt are carefully selected. A durable, injection-moulded IP67 enclosure enables indoor and outdoor installation, while the adjustable pole mounting system allows precise alignment and tilt adjustment to match the layout of each site.
