Antenna QuSpot for Teltonika RUTC50

P/n: AC50S

INTEGRATED MULTI-BAND LTE & 5G OMNI ANTENNA + WI-FI OMNI ANTENNA + GPS ACTIVE ANTENNA + PLACE TO INSTALL TELTONIKA RUTC50 (ALL-IN-ONE)

QuSpot for RUTC50 is an outdoor antenna designed to provide reliable wireless connectivity in a variety of environments. This product is an all in one solution that integrates a high gain omnidirectional 5G and Wi Fi antennas with RUTC50 into a single IP67 enclosure. Such integration allows implementation of new outdoor RUTC50 solutions.

QuSpot for RUTC50 is an ideal solution for outdoor wireless connectivity in moving applications such as transportation, yachting, boats and camping but also city centres with high signal density.

Why QuSpot for Teltonika RUTC50

Learn more about your profit

Outdoor antenna works in any weather conditions, IP67

Antenna perfectly matched with the router

Passive PoE support

Made in Europe

QuSpot for Teltonika RUTC50

SPECIFICATION

PRODUCT DETAILS

5G antenna specification

Wi-Fi antenna specification

GPS Active antenna specification

Mechanical specification

Frequency bands

COMPATIBLE ROUTERS

Frequency

617 - 960 MHz

1.7 - 2.7 GHz

3.3 - 4.3 GHz

Gain

617 - 960 MHz : 2 dBi

1.7 - 2.7 GHz : 4 dBi

3.3 - 4.3 GHz : 4.5 dBi

Supported LTE bands

1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, 1067, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, n77, n78, n80, n81, n82, n83, n84, n86, n89, n90, n95, n97, n98, n100, n101

Supported 5G bands

n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n48, n53, n65, n66, n67, n71, n77, n78, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n256

VSWR

<2.00, max <2.50

Beamwidth

360°/25° ±5°

Polarization

Vertical

Impedance

50 Ω

Connector

4x SMA

Cable type

RG316

PLOTS

PRODUCT DETAILS

VSWR for 5G/LTE antenna

VSWR for 5G/LTE antenna of QuSpot for Teltonika RUTC50

VSWR for Wi-Fi antenna

VSWR for Wi-Fi antenna of QuSpot for Teltonika RUTC50

Gain for 5G/LTE antenna

Gain for 5G/LTE antenna of QuSpot for Teltonika RUTC50

Gain for Wi-Fi antenna

Gain for Wi-Fi antenna of QuSpot for Teltonika RUTC50
5G/LTE from 617MHz to 960MHz
Elevation
Azimuth
5G/LTE from 1.71GHz to 2.5GHz
Elevation
Azimuth
5G/LTE from 3.3GHz to 4.2GHz
Elevation
Azimuth
Wi-Fi 2.4 GHz and 5 GHz
Elevation
Azimuth

ANY QUESTIONS?

contact us

DIMENSIONS

PRODUCT DETAILS
QuSpot for Teltonika RUTC50QuSpot for Teltonika RUTC50
QuSpot for Teltonika RUTC50QuSpot for Teltonika RUTC50

WHAT'S IN THE BOX?

PRODUCT DETAILS

In the box

QuSpot for RUTC50

Parts of QuSpot for Teltonika RUTC50
1x With mounting for Teltonika RUTC50
Parts of QuSpot for Teltonika RUTC50
1x 8mm wrench
Parts of QuSpot for Teltonika RUTC50
x4 3,1 x 12
Parts of QuSpot for Teltonika RUTC50
4x M6 x 10
Parts of QuSpot for Teltonika RUTC50
4x
Parts of QuSpot for Teltonika RUTC50
1x
Parts of QuSpot for Teltonika RUTC50
2x M8
Parts of QuSpot for Teltonika RUTC50
1x
Parts of QuSpot for Teltonika RUTC50
1x QuRJ45
