Antenna QuCube for Teltonika

P/n: -

INTEGRATED MULTI-BAND 5G OMNI ANTENNA + WI-FI 6E OMNI ANTENNA + GPS ANTENNA + BLUETOOTH ANTENNA + PLACE TO INSTALL TELTONIKA (ALL-IN-ONE)

QuCube for Teltonika is a perfect outdoor device for mobile and fixed installations like industrial, CCTV, hotspots, yachts, boats, campers, RV etc. It has embedded omni 5G, omni Wi-Fi 6E, BT and GPS antenna. If you use Teltonika router with QuCube antenna, you get an integrated complete solution with embedded router and multi band antennas in one enclosure.

Additional accessory: a QuPoE splitter, allowing you to split data and power from a single Ethernet cable and maintain gigabit transfer speeds while protecting the LAN port from damage caused by overvoltage, short circuit or improper connection.

Technical specification

Any question?

Contact us

Why QuCube for Teltonika

Learn more about your profit

OUTDOOR ANTENNA WORKS IN ANY WEATHER CONDITIONS, IP68

ANTENNA PERFECTLY MATCHED WITH THE TELTONIKA ROUTERS

ALL ANTENNAS AND TELTONIKA ROUTER INTEGRATED IN ONE ENCLOSURE

Galvanized steel, wall or pole mounting bracket

Made in Europe

QuCube for Teltonika

SPECIFICATION

PRODUCT DETAILS

5G / LTE ANTENNA SPECIFICATION

WI-FI ANTENNA SPECIFICATION

GPS ACTIVE ANTENNA SPECIFICATION

MECHANICAL SPECIFICATION

FREQUENCY BANDS

Frequency

617 - 960 MHz

1.7 - 2.7 GHz

3.3 - 6.0 GHz

Gain

617 - 960 MHz : 2 dBi

1.7 - 2.7 GHz : 3 dBi

3.3 - 6.0 GHz : 4 dBi

Supported LTE bands

1, 2, 3, 4, 5, 7, 8, 9, 10, 12, 13, 14, 17, 18, 19, 20, 22, 25, 26, 27, 28, 29, 30, 33, 34, 35, 36, 37, 38, 39, 40, 41, 42, 43, 44, 46, 47, 48, 49, 52, 53, 65, 66, 67, 68, 69, 71, 85, 103, 106

Supported 5G bands

n1, n2, n3, n5, n7, n8, n12, n13, n14, n18, n20, n25, n26, n28, n29, n30, n34, n38, n39, n40, n41, n46, n47, n48, n53, n65, n66, n67, n71, n77, n78, n79, n80, n81, n82, n83, n84, n85, n86, n89, n90, n95, n97, n98, n100, n101, n256

VSWR

<1.20, max <2.50

Beamwidth

360°/35° ±5°

Polarization

Vertical

Impedance

50 Ω

Connector

4x SMA

Cable type

RG316

PLOTS

PRODUCT DETAILS

5G/LTE VSWR

5G/LTE VSWR of QuCube for Teltonika

5G/LTE Gain

5G/LTE Gain of QuCube for Teltonika

WI-FI VSWR

WI-FI VSWR of QuCube for Teltonika

WI-FI Gain

WI-FI Gain of QuCube for Teltonika
5G/LTE From 617MHz to 960MHz
Elevation
Azimuth
5G/LTE From 1.71GHz to 2.5GHz
Elevation
Azimuth
5G/LTE From 3.3GHz to 4.2GHz
Elevation
Azimuth
5G/LTE From 4.8GHz to 5.8GHz
Elevation
Azimuth
Wi-Fi From 2.4 GHz to 5.8 GHz
Elevation
Azimuth

ANY QUESTIONS?

contact us

DIMENSIONS

PRODUCT DETAILS
QuCube for TeltonikaQuCube for Teltonika
QuCube for TeltonikaQuCube for Teltonika

Download

Datasheet QuCube for Teltonika
Download
